Background & Objective: Epithelial-Mesenchymal transition (EMT) is known to be a possible mechanism in tumor progression; however, there is insufficient evidence to support the contribution of this process in human cancers. The present study aimed to evaluate the expression of EMT markers in normal oral epithelium and oral squamous cell carcinoma and also correlates with some clinicopathological parameters.
Methods: This study was conducted on 70 samples, including 20 cases of normal epithelium and 50 cases of Oral Squamous cell Carcinoma (OSCC). To examine the expression level of these proteins, immunohistochemical staining was performed for samples using E-cadherin and N-cadherin monoclonal antibodies.
Results: Reduced expression of E-cadherin was observed in 74% of OSCC and 15% of normal epithelium samples; this difference was statistically significant (P˂0.000). With the progression of SCC from well towards poor differentiation, the E-cadherin expression decreased; however, this difference was not statistically significant (P=0.642). Normal epithelial specimens were negative for N-cadherin expression in 75% of cases, whereas OSCC specimens showed high expression of N-cadherin in 46% of cases, this difference was statistically significant (P=0.01). Although 62.5% of poorly differentiated OSCC showed high expression of N-cadherin, the difference between the histopathological grades was not significant (P=0.586). No significant relationship was found between markers expression and patient’s age, gender, and tumor location.
Conclusion: This study showed that OSCC tissues showed high EMT phenotype (reduced E-cadherin expression and high expression of N-cadherin) compared to normal oral mucosa which may indicate the possible key role of EMT mechanism during oral carcinogenesis.
Oral Squamous Cell Carcinoma (OSCC), is the sixth most prevalent cancer in the world (1-4). More than 400,000 people die due to OSCC annually. The 5-year survival rate for patients with SCC is relatively weak and less than 60% (5-7). Poor prognosis of OSCC is due to its invasion into adjacent tissues and metastasis; therefore, identifying biological markers which can provide prognostic information of tumor is helpful (8-10).
The EMT is an early cellular process which is involved in tissue remodeling during development. In cancer, the EMT plays a critical role in tumor prog-ression to more aggressive phenotype (11). During the EMT process, polarized epithelial cells lose their polarity and cell-cell adhesion; they transform into mesenchymal cells and actually acquire the charac-teristics of invasion and migration.(12-14). One of the well-known processes in EMT is breakage in junctions between epithelial cells and reduction in the E-cadherin expression (epithelial cadherin), whereas cells clearly express high levels of N-cadherin (mesenchymal cadherin). The aforementioned process is called cadherin switching (12-15).
Oral epithelial cells are joined by tight cell-cell adhesion mediated by cadherins. The cadherins are a large family of widely regulated and conserved calcium-dependent membrane-binding proteins. The E-cadherin and N-cadherin are prominent members of the cadherin family (16, 17).
The transmembrane glycoprotein E-cadherin plays a vital role in maintaining the structural integrity, function of adhesion molecules and desmosomal junctions. In addition, it regulates various aspects of cellular behavior (e.g., growth, differentiation, polari-zation, and classification of epithelial cells). This gly-coprotein is primarily responsible for cell-cell adhesion in epithelial tissue, and it lack increased epithelial cell motility and local invasion ability, which is recognized as an EMT sign during tumor progression (13, 18).
The N-cadherin is a calcium-binding protein which has been found primarily in neural and striated muscle tissues. Increased expression of N-cadherin has been reported in tumors, such as leiomyoma, pheochromocytoma, adrenocortical carcinoma (19).
Although epithelial cells do not express N-cadherin, they may acquire it during the cadherin switching process. This process occurs during EMT and enhances cellular motility and their invasive properties (13, 20).
Several studies and experimental models have indicated that the EMT is an important mechanism in malignant phenotype and metastasis in cancers. However, its role in human cancer, including head and neck SCC is controversial (21-23).
Since studies on EMT and potential relation with histopathological grading in Oral cancer are sparse (24), this study aims to evaluate the expression of EMT- associated proteins E-cadherin and N-cadherin in OSCC.
Material and Methods
Following the approval of this study by local Ethics Committee (7479) we analyzed 70 specimens consisting of 50 OSCC and 20 normal epithelia obtained from department of oral pathology in Zahedan Dental School, Iran, by census sampling method between 2005 and 2019. This was a retrospective study using previously diagnosed samples. All H&E slides were reviewed for confirmation of diagnosis and classification of the OSCC samples as well differentiated, moderately differentiated and poorly differentiated, according to International Histological Classification of Tumors (25). Demographic and clinicopathological data of the samples were extracted from patient’s records.
For control group, the normal epithelium without inflammation was obtained from the gingiva tissue (patients who had undergone crown lengthening surgery and had no history of head and neck carcino-mas). All samples with sufficient tissue were included for immunohistochemical analysis.
For IHC staining, paraffin- embedded samples were segmented into 4 µm sections, the samples were deparaffinized with xylene and rehydrated with 100%, 90% and 80% alcohols solution. Antigen retrieval was performed by microwave heating for 30 min on Tris buffer (pH = 7.6). Then, the sections were incubated for 1 h at room temperature with primary mousem-onoclonal anti-human antibody N- Cadherin Clone 6044777 (Novocastra, United Kingdom), E- Cadherin Clone 36B5 (Novocastra, United Kingdom) according to the manufacturer’s instructions. Then, sections were washed with PBS at room temperature, and secondary antibody was applied. The immune complexes were incubated with streptavidin peroxidase (Novo Link Polymer Detection system). The immune reaction was developed with diaminobenzidine and counterstained with Mayer’s hematoxylin. Finally, the sections were dehydrated in alcohol and cleared in xylene, and slides were mounted in Permount. In negative controls primary antibody was omitted. The samples of Breast cancer tissue and normal testis were used as positive control for E-cadherin and N-cadherin respectively.
The result of immunohistochemical staining was evaluated by a pathologist under a light microscope (Nikon, Type2, Tokyo, Japan). Immunostaining was assessed in 10 high-power fields (HPF) at a magnification of 400, and scored as described in other studies (26, 27). For N-cadherin the samples were divided into low expression (membranous and cyto-plasmic immunostaining in less than 20% of the epithelial tumor cells) and high expression (mem-branous and cytoplasmic immunostaining in 20% or more of the epithelial tumor cells). E-cadherin was defined as preserved (membranous immunostaining in more than 80% of the epithelial tumor cells) and reduced (membranous immunostaining in 80% or less of the epithelial tumor cells).
Data analysis was performed using SPSS 21(SPSS Inc, Chicago, IL., USA). The relationship between the groups was assessed by Mann-Whitney and Kruskal Wallis tests. P-value less than 0.05 was considered statistically significant.
In the current study, 70 specimens were examined (including 50 cases of OSCC with mean age of 57.1±15.18 years and 20 cases of the normal epithelium as the control group with mean age of 33.45±5.34 years). Table 1 shows the demographic data of OSCC samples.
|Clinical data||FrequencyN (%)|
In normal epithelium, basal and suprabasal cells showed the highest amount of membrane staining in relation to E-cadherin, and gradually decreased in cells that had undergone to keratinization (Figure 1a).
About 74% of SCC samples showed reduced expression of E-cadherin but in normal epithelium only 15% of cases showed reduced expression of E-cadherin and according to the Mann-Whitney test this difference was significant (P<0.000). The results are expressed in Table 2 and Figure 1.
In addition, the results of the present study showed reduction in E-cadherin expression with progression of SCC from well to poor differentiation; however, this difference was not statistically significant (P=0.642) (Table 3).
The expression of E-cadherin was not correlated with patient’s gender (P=0.899), age (P=0.790) and location of tumor (P=0.311).
Regarding the expression of N-cadherin, normal epithelial specimens were negative in 75% of cases and did not express this protein and only 5(15%) cases showed low expression of N-cadherin. Whereas in the SCC group, 50% of the samples showed no expression of N-cadherin and 46% showed high expression of N-cadherin and according to Mann-Whitney test the difference between the groups was significant (P=0.01) which are shown in Table 2 and Figure 2.
The majority of well differentiated cases (60.9%) did not express N-cadherin. Moreover, moderately, and poorly differentiated of OSCC samples showed 52.6% and 62.5% high expression of N-cadherin, respectively; however, these differences were not significant (P=0.586) (Table 3).
No relationship was observed between N-cadherin expression and patient’s gender (P=0.055), age (P=0.511) and location of tumor (P=0.471).
Also, as shown in Table 4, out of 50 SCC cases, 26% (n=13) showed cadherin switching (reduction in the E-cadherin expression and the subsequent gain of N-cadherin expression in the same cell population).
The EMT is defined as the switching of polarized epithelial cells to the fibroblastoid migratory phenotype which occurs in many evolutionary processes and during tumor metastasis; however, the precise role of this process in tumor development or progression is still a debating issue (19, 28).
In the present study, the expression of E-cadherin and N-cadherin proteins in OSCC and normal epithelium samples were examined. Based on the current findings, the OSCC samples showed a reduced expression of E-cadherin, compared to the control group. In addition, although 75% of the control group samples did not express N-cadherin, 46% of SCC samples showed high expression of N-cadherin and this difference was significant. The obtained results denoted that EMT plays a possible key role in the development and evolution of OSCC.
Furthermore, in the present study, with the prog-ression of SCC from well towards poor differentiation, reduction in E-cadherin protein expression and high expression of N-cadherin was observed; however, these differences were not statistically significant due to the low sample size and inappropriate distribution of the samples selected from various histopathological grades.
Similar to the present study, Guo et al. (29) showed that from normal oral mucosa to OSCC and with the progression of tumor, E-cadherin expression decreased and N-cadherin expression increased (both human and animal models). Also, they revealed that E-cadherin expression in metastatic lymph nodes increased again. It is well known that switching from E-cadherin to N-cadherin may be due to the loss of adhesion between cells, which causes the tumor cells to separate from the primary tumor, migrate and eventually metastasize. According to the aforementioned study, when cancer cells reach metastatic target tissue, E-cadherin expression occurs again resulting in colonization of cancer cells in invasive tissues. This condition is probably a dynamic adjustment of the proteins expression with micro-environmental changes and the E-cadherin expression is time- and space-dependent.
Pyo et al. (30) found that reduced expression of E-cadherin and increased expression of N-cadherin are associated with OSCC and suggested that cadherin switching plays an important role in the development of OSCC.
Angadi et al. (24) reported a high level of EMT phenotype (decreased E-cadherin and ß-catenin expression and increased N-cadherin expression) in OSCC tissues.
Zidar et al. (23) showed that decreased focal E-cadherin expression was observed in a very few cases of oral SCC and most cases showed fully preserved E-cadherin expression. In addition, N-cadherin expression was not observed in any of the OSCC cases. They were not found, any evidence that EMT contributes to SCC progression and metastasis, which is contrary to our study. Zidar et al. reported that the case-selection was one reason for their findings. It means that, all patients at the early stages of SCC were moderate differentiation; therefore, the potential role of EMT in progression and metastasis cannot be ignored at higher OSCC stages or its poor differentiation.
Ozaki-Honda et al. (31) investigated the expression of E-cadherin and N-cadherin in OSCC cells in two areas of tumor nest and invasive front. Cells expressed N-cadherin and E-cadherin in both regions; however, only N-cadherin expression in both regions was associated with the patient prognosis and was reported to be a helpful marker in the diagnosis of small tumor satellite and OSCC cells with the EMT.
In another study performed by Rai et al. (12), it was shown that with progression of tumor from low to high histopathological grade, the expression of N-cadherin protein increased. Accordingly, N-cadherin in different grades of SCC can be useful in predicting tumor progression.
Costa et al. (13) studied the expression of EMT markers (E-cadherin, N-cadherin and vimentin) in OSCC. Decreasing in E-cadherin expression was observed in 75% of OSCC samples in the invasion front region; it was also related to histological invasiveness. All cases of OSCC were negative for N-cadherin and 30% of OSCC were positive for vimentin, there was no correlation between the expression of each protein in IF with the tumor stage or nodal status. Also, no correlation was found between E-cadherin and N-cadherin expression (13).
The E-cadherin is the major adhesion molecule in epithelial tissues, it is required to establish and maintain the integrity of the epithelial structure. Several mechanisms have been proposed to inactivate E-cadherin protein in human malignant tumors. Since the lack of E-cadherin increases the mobility of epithelial cells, an EMT marker is considered during the metastatic invasion.
Several studies have shown that although cadherin-switching is required for increasing the motility, it is not necessary for EMT-related morphological changes (19).
Hashimoto et al. (16) also reported reduced expression of E-cadherin in OSCC, this decrease was related to tumor differentiation; however, N-cadherin positivity was very limited and did not correlate with clinicopathologic parameters. Moreover, in this study, mouse tongue tumors xenotransplanted oral SCC cell lines expressed both N-cadherin and E-cadherin in vitro; however, in vivo conditions, N-cadherin expression were negligible, despite E-cadherin depletion. Therefore, reduction in the E-cadherin expression rather than cadherin-switching contributes to the OSCC progression. Also, the surrounding environment of carcinoma cells affect cadherin expression largely (16).
Conversely, in a study performed by Domenico et al. (19), the expression of N-cadherin in neoplastic tissues was higher than normal and it was correlated with histopathological grade and stage of the patients. In addition, it was found that with increasing in the N-cadherin expression, OSCCs show poor prognosis and become more prone to metastasis. Lawson et al. (32) also reported increase of invasiveness in N-cadherin expressing cells of OSCC.
Another study demonstrated that, the 5-year metastatic risk in patients with low expression of E-cadherin was more than patients with high expression of E-cadherin (81% versus 19%). Also, all Head and Neck SCC patients with EMT phenotype (low expression of E-cadherin and high expression of vimentin) had higher distant metastasis formation (33).
Kong et al. in their study examined EMT related markers (CDH1, LAMC2, SNAI1/2, TWIST1, ZEB1 and ZEB2) in OSCC. In this study reduced expression of CDH1 (E-cadherin), overexpression of LAMC2, SnaiI1/2 and TWIST1 were observed. Loss of CDH1 was correlated with Broder’s grading significantly, while diffused LAMC2 was correlated with non-cohesive pattern of invasion similarly. Remarkably, co-expression of TWIST1 and ZEB2 was correlated with poorer overall survival in OSCC, particularly in patients with no lymph node metastasis (34).
The N-cadherin supports the systemic spread of tumor cells by enabling their association with stroma and endothelium in distant locations. It has been suggested that the interaction of cadherins with other cell-surface proteins (e.g., growth factor receptors) is the probable reason that E-cadherin and N-cadherin exhibit different phenotypes and behaviors in similar cellular contexts. (19).
Therefore, further studies on cadherin regulation by cellular environments are needed to understand the mechanism of OSCC progression.
According to the results of the present study, reduced expression of E-cadherin and high expression of N-cadherin are probable factors involved in the progression of normal mucosa toward SCC. Further-more, they are valuable markers in the EMT process during tumor progression.
- Sharada P, Swaminathan U, Nagamalini BR, Kumar KV, Ashwini BK, Lavanya V. Coalition of E-cadherin and vascular endothelial growth factor expression in predicting malignant transformation in common oral potentially malignant disorders. J Oral Maxillofac Pathol. 2018; 22(1):40-7.
- Huang C, Song H, Lai L. The role and mechanism of microRNA18a5p in oral squamous cell carcinoma. Mol Med Rep. 2019; 20(2):1637-44.
- Dhanuthai K, Rojanawatsirivej S, Thosaporn W, Kintarak S, Subarnbhesaj A, Darling M. Oral cancer: A multicenter study. Med Oral Patol Oral Cir Bucal. 2018; 23(1):e23-e9.
- Roi A, Roi CI, Negruțiu ML, Riviș M, Sinescu C, Rusu L-C. The challenges of OSCC diagnosis: Salivary Cytokines as potential biomarkers. J Clin Med. 2020; 9(9):2866.
- Kim JW, Park Y, Roh JL, Cho KJ, Choi SH, Nam SY. Prognostic value of glucosylceramide synthase and P-glycoprotein expression in oral cavity cancer. Int J Clin Oncol. 2016; 21(5):883-9.
- Su CC, Lee KI, Chen MK, Kuo CY, Tang CH, Liu SH. Cantharidin Induced Oral Squamous Cell Carcinoma Cell Apoptosis via the JNK-Regulated Mitochondria and Endoplasmic Reticulum Stress-Related Signaling Pathways. PLoS One. 2016; 11(12):e0168095.
- Lopes NM, Xavier FCA, Ortiz RC, Amôr NG, Garlet GP, Lara VS. Subcellular localization and expression of E-cadherin and SNAIL are relevant since early stages of oral carcinogenesis. Pathol Res Pract. 2018; 214(8):1185-91.
- Cruz MC, Pereira AL, Lopes FF, Nonaka CF, Silva RR, Freitas Rde A. Immunohistochemical expression of E-cadherin and CD44v6 in squamous cell carcinomas of the lower lip and tongue. Braz Dent J. 2009; 20(1):64-9.
- Hung KF, Chang CS, Liu CJ, Lui MT, Cheng CY, Kao SY. Differential expression of E‐cadherin in metastatic lesionscomparing to primary oral squamous cell carcinoma. J oral Pathol Med. 2006; 35(10):589-94.
- Neves AdC, Mesquita RA, Novelli MD, Toddai E, Sousa SOMD. Comparison between immunohistochemical expression of cyclin D1 and p21 and histological malignancy graduation of oral squamous cell carcinomas. Braz Dent J. 2004; 15(2):93-8.
- Agiostratidou G, Hulit J, Phillips GR, Hazan RB. Differential cadherin expression: potential markers for epithelial to mesenchymal transformation during tumor progression. J Mammary Gland Biol Neoplasia. 2007; 12(2-3):127-33.
- Rai H, Ahmed J. A Correlative Study of N-Cadherin Expression with Different Grades of Oral Squamous Cell Carcinoma Projecting as a Marker of Epithelial to Mesenchymal Transition in Tumor Progression. Asian Pacific journal of cancer prevention: APJCP. 2019; 20(8):2327-32.
- COSTA LCMC, Leite CF, Cardoso SV, Loyola AM, FARIA PRd, SOUZA PEA. Expression of epithelial-mesenchymal transition markers at the invasive front of oral squamous cell carcinoma. Journal of Applied Oral Science. 2015; 23(2):169-78.
- Radisky DC. Epithelial-mesenchymal transition. J Cell Sci. 2005; 118(19):4325-6.
- Krisanaprakornkit S, Iamaroon A. Epithelial-mesenchymal transition in oral squamous cell carcinoma. ISRN Oncol. 2012;2012:681469.
- Hashimoto T, Soeno Y, Maeda G, Taya Y, Aoba T, Nasu M. Progression of oral squamous cell carcinoma accompanied with reduced E-cadherin expression but not cadherin switch. PloS one. 2012; 7(10):e47899.
- Imai K, Maeda G, Chiba T. Cadherin expression and progression of head and neck squamous cell carcinomas Squamous Cell Carcinoma Rijeka. InTech-Open Science. 2012;121-36.
- Ye P, Chapple CC, Kumar RK, Hunter N. Expression patterns of E-cadherin, involucrin, and connexin gap junction proteins in the lining epithelia of inflamed gingiva. J Pathol. 2000; 192(1):58-66.
- M DID, Pierantoni GM, Feola A, Esposito F, Laino L, A DER. Prognostic significance of N-Cadherin expression in oral squamous cell carcinoma. Anticancer Res. 2011; 31(12):4211-8.
- Hazan RB, Qiao R, Keren R, Badano I, Suyama K. Cadherin switch in tumor progression. Ann N Y Acad Sci. 2004; 1014(1):155-63.
- Ocana OH, Corcoles R, Fabra A, Moreno-Bueno G, Acloque H, Vega S. Metastatic colonization requires the repression of the epithelial-mesenchymal transition inducer Prrx1. Cancer Cell. 2012; 22(6):709-24.
- Tsai JH, Donaher JL, Murphy DA, Chau S, Yang J. Spatiotemporal regulation of epithelial-mesenchymal transition is essential for squamous cell carcinoma metastasis. Cancer cell. 2012; 22(6):725-36.
- Zidar N, Bostjancic E, Malgaj M, Gale N, Dovsak T, Didanovic V. The role of epithelial-mesenchymal transition in squamous cell carcinoma of the oral cavity. Virchows Arch. 2018; 472(2):237-45.
- Angadi PV, Patil PV, Angadi V, Mane D, Shekar S, Hallikerimath S. Immunoexpression of Epithelial Mesenchymal Transition Proteins E-Cadherin, beta-Catenin, and N-Cadherin in Oral Squamous Cell Carcinoma. Int J Surg Pathol. 2016; 24(8):696-703.
- Barnes L, Eveson J, Reichart P, Sidransky D. World Health Organization classifications tumours. Pathology and genetics of head and neck tumours. 2005.
- Nguyen PT, Kudo Y, Yoshida M, Iizuka S, Ogawa I, Takata T. N‐cadherin expression is correlated with metastasis of spindle cell carcinoma of head and neck region. J Oral Pathol Med. 2011; 40(1):77-82.
- Nguyen PT, Kudo Y, Yoshida M, Kamata N, Ogawa I, Takata T. N-cadherin expression is involved in malignant behavior of head and neck cancer in relation to epithelial-mesenchymal transition. Histol Histopathol. 2011.
- Guarino M, Rubino B, Ballabio G. The role of epithelial-mesenchymal transition in cancer pathology. Pathology. 2007; 39(3):305-18.
- Guo M, Mu Y, Yu D, Li J, Chen F, Wei B. Comparison of the expression of TGFβ1, Ecadherin, Ncadherin, TP53, RB1CC1 and HIF1α in oral squamous cell carcinoma and lymph node metastases of humans and mice. Oncol Lett. 2018; 15(2):1639-45.
- Pyo SW, Hashimoto M, Kim YS, Kim CH, Lee SH, Johnson KR. Expression of E-cadherin, P-cadherin and N-cadherin in oral squamous cell carcinoma: correlation with the clinicopathologic features and patient outcome. J Craniomaxillofac Surg. 2007; 35(1):1-9.
- Ozaki-Honda Y, Seki S, Fujiwara M, Matsuura M, Fujita S, Ikeda H. Prognostic prediction of oral squamous cell carcinoma by E-cadherin and N-cadherin expression in overall cells in tumor nests or tumor cells at the invasive front. Cancer Microenviron. 2017; 10(1-3):87-94.
- Lawson KR, Wheelock MJ, Johnson KR. Modulation of E-and N-cadherin levels in oral squamous carcinoma cells reveals N-cadherin-specific increases in invasion-related signaling pathways. Proc Amer Assoc Cancer Res. 2006; 66(8):653.
- Nijkamp MM, Span PN, Hoogsteen IJ, van der Kogel AJ, Kaanders JH, Bussink J. Expression of E-cadherin and vimentin correlates with metastasis formation in head and neck squamous cell carcinoma patients. Radiother Oncol. 2011; 99(3):344-8.
- Kong YH, Syed Zanaruddin SN, Lau SH, Ramanathan A, Kallarakkal TG, Vincent-Chong VK. Co-expression of TWIST1 and ZEB2 in oral squamous cell carcinoma is associated with poor survival. PloS one. 2015; 10(7):e0134045.
